Mazda CX-5 II (2017-2022) left rear speaker Wiring diagrams
This page contains all the electrical diagrams for the component. left rear speaker, in which he is found in the car Mazda CX-5 II (2017-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
left rear speaker wiring diagram (1 of 4)
0920-311
0920-313
ANT CONT
ANTENNA AMPLIFIER
AUX DET
AUX L +
AUX LR
AUX R +
BLK WIRE
BLU WIRE
BRN WIRE
C-14
C-17
C-18
C-19
C-21
C-27
C-28
C-79
C-80
CENTER DISPLAY
CENTER ROOF ANTENNA
COMPUTER DATA LINES SYSTEM
DATA
F SP L+
F SP R+
GRN WIRE
GRY WIRE
IN L-
IN R+
J/C C-62
J/C C-70
J/C C-74
LEFT FRONT DOOR SPEAKER
LEFT REAR SPEAKER
LEFT TWEETER
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PILOT
PNK WIRE
R SP L-
R SP R+
RADIO (OR GND)
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT DOOR SPEAKER
RIGHT REAR SPEAKER
RIGHT TWEETER
RS 485-
TAN WIRE
TUNER, AMP UNIT
V-BUS
VIO WIRE
WHT WIRE
WHT/BLK WIRE
XM/GND
YEL WIRE
Go to component -> Navigation circuit, w/ bose 20-pin (4 of 4) -> LEFT REAR SPEAKER
left rear speaker wiring diagram (2 of 4)
0920-311
0920-313
AMP CONT
ANT CONT
ANT CONT XM/GND
ANTENNA AMPLIFIER
AUX DET
AUX L +
AUX LR
AUX R +
BLK WIRE
BLU WIRE
BRN WIRE
C-14
C-17
C-18
C-19
C-21
C-27
C-28
C-79
C-80
CENTER DISPLAY
CENTER ROOF ANTENNA
COMPUTER DATA LINES SYSTEM
DATA
F SP L+
F SP R+
GRN WIRE
GRY WIRE
HS CAN+
IN L-
IN R+
J/C C-62
J/C C-70
J/C C-74
LEFT FRONT DOOR SPEAKER
LEFT REAR SPEAKER
LEFT TWEETER
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PILOT
PNK WIRE
R SP L-
R SP R+
RADIO (OR GND)
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT DOOR SPEAKER
RIGHT REAR SPEAKER
RIGHT TWEETER
TAN WIRE
TUNER, AMP UNIT
V-BUS
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Navigation circuit, w/ bose 24-pin (4 of 4) -> LEFT REAR SPEAKER
left rear speaker wiring diagram (3 of 4)
0920-311
0920-313
ANT CONT
ANTENNA AMPLIFIER
AUX DET
AUX L +
AUX LR
AUX R +
BLK WIRE
BLU WIRE
BRN WIRE
C-14
C-17
C-18
C-19
C-21
C-27
C-28
C-79
C-80
CENTER DISPLAY
CENTER ROOF ANTENNA (WITH SIRIUS)
COMPUTER DATA LINES SYSTEM
DATA
F SP L+
F SP R+
GRN WIRE
GRY WIRE
IN L-
IN R+
J/C C-62
J/C C-70
J/C C-74
LEFT FRONT DOOR SPEAKER
LEFT REAR SPEAKER
LEFT TWEETER
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PILOT
PNK WIRE
R SP L-
R SP R+
RADIO (OR GND)
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT DOOR SPEAKER
RIGHT REAR SPEAKER
RIGHT TWEETER
RS 485-
TAN WIRE
TUNER, AMP UNIT
V-BUS
VIO WIRE
WHT WIRE
WHT/BLK WIRE
XM/GND
YEL WIRE
Go to component -> Radio circuit, w/ bose 20-pin (4 of 4) -> LEFT REAR SPEAKER
left rear speaker wiring diagram (4 of 4)
0920-311
0920-313
AMP CONT
ANT CONT
ANT CONT XM/GND
ANTENNA AMPLIFIER
AUX DET
AUX L +
AUX LR
AUX R +
BLK WIRE
BLU WIRE
BRN WIRE
C-14
C-17
C-18
C-19
C-21
C-27
C-28
C-79
C-80
CENTER DISPLAY
CENTER ROOF ANTENNA
COMPUTER DATA LINES SYSTEM
DATA
F SP L+
F SP R+
GRN WIRE
GRY WIRE
HS CAN+
IN L-
IN R+
J/C C-62
J/C C-70
J/C C-74
LEFT FRONT DOOR SPEAKER
LEFT REAR SPEAKER
LEFT TWEETER
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PILOT
PNK WIRE
R SP L-
R SP R+
RADIO (OR GND)
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT DOOR SPEAKER
RIGHT REAR SPEAKER
RIGHT TWEETER
TAN WIRE
TUNER, AMP UNIT
V-BUS
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Radio circuit, w/ bose 24-pin (4 of 4) -> LEFT REAR SPEAKER
