Car Wiring Diagrams for 4wd circuit for Mazda CX-5 I facelift (2015-2017)

AT FUSE AWD CONTROL MODULE AWD SOLENOID BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE C-08 C-14 C-26 COMPUTER DATA LINES SYSTEM DIFFERENTIAL OIL TEMPERATURE SENSOR GRN WIRE GRN/BLK WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER LT GRN/RED WIRE METER 1 FUSE MICROCOMPUTER PNK WIRE RED/YEL WIRE RELAY & FUSE BLOCK VIO/RED WIRE VIO/WHT WIRE WARNING/ INDICATOR LIGHTS WHT/BLK WIRE YEL WIRE
