Mazda CX-5 I facelift (2015-2017) w/o smart brake support w/ smart brake support Wiring diagram
This page shows the only wiring diagram for the component.w/o smart brake support w/ smart brake support, which is found in the car Mazda CX-5 I facelift (2015-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o smart brake support w/ smart brake support (1 of 1)
ABS/DSC M FUSE
ABS/DSC S FUSE
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BRAKE LIGHT RELAY (STOP)
BRAKE LIGHT UNIT
BRN WIRE
C-04
C-05
C-08
C-11
COMPUTER DATA LINES SYSTEM
DSC HU/CM
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
LASER SENSOR
LEFT FRONT ABS WHEEL SPEED SENSOR
LEFT REAR ABS WHEEL SPEED SENSOR
LT GRN/BLK WIRE
NCA WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RELAY & FUSE BLOCK
RELAY ENERGIZED
RIGHT FRONT ABS WHEEL SPEED SENSOR
RIGHT REAR ABS WHEEL SPEED SENSOR
STOP FUSE
VIO WIRE
VIO/GRN WIRE
VIO/WHT WIRE
W/O SMART BRAKE SUPPORT W/ SMART BRAKE SUPPORT
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> W/O SMART BRAKE SUPPORT W/ SMART BRAKE SUPPORT
