Mazda CX-5 I facelift (2015-2017) center console Wiring diagrams
This page contains all the electrical diagrams for the component. center console, in which he is found in the car Mazda CX-5 I facelift (2015-2017). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
center console wiring diagram (1 of 2)
0518-101
0920-203
0920-303
0922-201
0922-202 CLOCK SPRING (IN STEERING COLUMN)
AUDIO UNIT
AUTO
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BUZZER
C-03
C-08
CENTER CONSOLE
CLUSTER SWITCH
COMMANDER SWITCH
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SWITCH
DIMMER CANCEL SWITCH
DRIVE SELECTION SWITCH
ELECTRIC PARKING BRAKE SWITCH
FBCM
GRN WIRE
GRN/BLK WIRE
GRY/BLU WIRE
HAZARD WARNING SWITCH
HEAD
HOT AT ALL TIMES
ILLUM
INSTRUMENT CLUSTER
J/C C-36
LIGHT SWITCH
METER 1 FUSE
MICROCOMPUTER
NCA WIRE
OFF
PANEL LIGHT CONTROL
RED/BLU WIRE
RED/YEL WIRE
RELAY & FUSE BLOCK
RELAY ENERGIZED
ROOM FUSE
SHIFT PANEL (INDICATOR)
START STOP UNIT
STEERING SWITCH
TNS
VIO WIRE
W/ BOSE, CENTER DISPLAY
W/O BOSE, W/ CENTER DISPLAY
WARNING/ INDICATOR LIGHTS
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Instrument illumination circuit -> CENTER CONSOLE
center console wiring diagram (2 of 2)
0518-101
AT FUSE
AT IND FUSE
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
C-03
C-08
C-09
CENTER CONSOLE
COMPUTER DATA LINES SYSTEM
DRIVE SELECTION SWITCH
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED FUSE BLOCK
INDICATOR
INSTRUMENT CLUSTER
LIGHTS)
METER 1 FUSE
MICROCOMPUTER
NCA WIRE
NOT P POSITION SWITCH
RED/WHT WIRE
RED/YEL WIRE
RELAY & FUSE BLOCK
RELAY ENERGIZED
SELECTOR LEVER COMPONENT
SHIFT LOCK SOLENOID
SHIFT PANEL (INDICATOR)
START STOP UNIT
VIO/YEL WIRE
WARNING
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Shift interlock circuit -> CENTER CONSOLE
