Car Wiring Diagrams for 4wd circuit for Mazda CX-5 I (2011-2015)

AT FUSE AWD CONTROL MODULE (RIGHT KICK PANEL) AWD IND AWD SOLENOID (NEAR REAR DIFFERENTIAL) BLK WIRE BLK/YEL WIRE BRN WIRE C-03 C-04 C-05 C-08 C-14 C-26 COMPUTER DATA LINES SYSTEM DIFFERENTIAL OIL TEMPERATURE SENSOR (ON REAR DIFFERENTIAL) FUSE GRN/BLK WIRE GRY/RED WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER LT GRN/RED WIRE METER 1 FUSE MICROCOMPUTER PNK C-26 WIRE PNK WIRE RED/YEL WIRE RELAY & FUSE BLOCK (LEFT REAR OF ENGINE COMPT) VIO/RED WIRE VIO/WHT WIRE WHT/BLK WIRE YEL WIRE YEL/RED WIRE
