Power top/sunroof circuit for Mazda CX-5 I (2011-2015)

Power top/sunroof circuit

Get access

BLK WIRE BLK/RED WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE C-05 C-08 C-11 CAN-L CAN-H CLOSE COMPUTER DATA LINES SYSTEM FUSE BLOCK (LEFT KICK PANEL) GRY/RED WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER RELAY ENERGIZED RELAY & FUSE BLOCK (LEFT REAR OF FUSE ENGINE COMPT) SUNROOF FUSE SUNROOF MOTOR (FORWARD OF SUNROOF) SUNROOF RELAY 1 SUNROOF RELAY 2 SUNROOF SWITCH TILT OPEN UP VIO WIRE VIO/RED WIRE VIO/WHT WIRE YEL/RED WIRE
