Mazda CX-5 I (2011-2015) right side turn light right power outer mirror Wiring diagram
This page shows the only wiring diagram for the component.right side turn light right power outer mirror, which is found in the car Mazda CX-5 I (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right side turn light right power outer mirror (1 of 1)
AB C-16
BLK WIRE
BLU WIRE
BRN WIRE
C-15
C-16
DEFOGGER SYSTEM
DOWN
DOWN UP
FUSE BLOCK (LEFT KICK PANEL)
GRN WIRE
GRY WIRE
GRY/RED WIRE
HEATED OUTER MIRROR
HOT W/ ACC RELAY ENERGIZED
J/C 15 (RIGHT KICK PANEL)
LEFT
LEFT BSM INDICATOR LIGHT LEFT POWER OUTER MIRROR
LEFT RIGHT
LEFT SIDE TURN LIGHT
LT GRN WIRE
MIRROR FUSE
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
POWER WINDOW MAIN SWITCH/ POWER OUTER MIRROR SWITCH
RED WIRE
RIGHT
RIGHT BSM INDICATOR LIGHT
RIGHT SIDE TURN LIGHT RIGHT POWER OUTER MIRROR
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component: -> Power mirror circuit -> RIGHT SIDE TURN LIGHT RIGHT POWER OUTER MIRROR
