Mazda CX-5 I (2011-2015) int on off rear washer Wiring diagram
This page shows the only wiring diagram for the component.int on off rear washer, which is found in the car Mazda CX-5 I (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram int on off rear washer (1 of 1)
AT FUSE
AUTOSTOP SWITCH
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
C-03
C-04
C-21
C-22
CIRCUIT BREAKER
COMPUTER DATA LINES SYSTEM
FRONT
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
INT ON OFF
INT ON OFF REAR WASHER
NCA WIRE
R WIPER FUSE
RBCM (LEFT SIDE OF LUGGAGE COMPT)
REAR WASHER
REAR WASHER MOTOR (IN WASHER FLUID RESERVOIR)
REAR WIPER MOTOR (CENTER OF LIFTGATE)
RED WIRE
RED/YEL WIRE
RELAY & FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
START STOP UNIT
VIO WIRE
WHT/BLK WIRE
WINDSHIELD WIPER, WASHER SWITCH/ REAR WIPER, WASHER SWITCH
YEL WIRE
Go to component -> Rear wiper/washer circuit -> INT ON OFF REAR WASHER
