Mazda CX-5 I (2011-2015) 0613-102 computer data lines system Wiring diagram

This page shows the only wiring diagram for the component.0613-102 computer data lines system, which is found in the car Mazda CX-5 I (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram 0613-102 computer data lines system (1 of 1)

Wiring diagram 0613-102 computer data lines system for Mazda CX-5 I (2011-2015)

Get access

0613-102 COMPUTER DATA LINES SYSTEM BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE C-04 C-08 C-09 COMPUTER DATA LINES SYSTEM EPAS IND EPS CONTROL MODULE (LOWER LEFT SIDE OF DASH) FUSE GRN/BLK WIRE HOT AT ALL TIMES MAIN FUSE (ON BATTERY) EPS FUSE HS CAN-H HS CAN-L INSTRUMENT CLUSTER MICRO COMPUTER RED/BLU WIRE RED/GRN WIRE RELAY & FUSE BLOCK METER FUSE (LEFT REAR OF ENGINE COMPT) RELAY ENERGIZED WHT WIRE WHT/BLU WIRE

Go to component: -> Electronic power steering circuit -> 0613-102 COMPUTER DATA LINES SYSTEM
