Car Wiring Diagrams for Warning systems circuit for Mazda CX-3 I facelift (2018-2024)

BCM (LEFT END OF DASH) BLK WIRE BLU WIRE BRAKE FLUID LEVEL SENSOR BUZZER C-10 C-15 C-20 CLUSTER SWITCH COMPUTER DATA LINES SYSTEM DRIVER-SIDE BUCKLE SWITCH GRN WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER INTERIOR FUSE J/C C-35 LEFT FRONT DOOR LATCH, LOCK ACTUATOR LT GRN WIRE METER 1 FUSE MICROCOMPUTER NCA WIRE PARKING BRAKE SWITCH (BASE OF PARKING BRAKE LEVER) PNK WIRE RED WIRE RELAY & FUSE BLOCK RELAY ENERGIZED SAS CONTROL MODULE (UNDER CENTER CONSOLE) START/STOP UNIT (LOWER LEFT SIDE OF DASH) TPMS SET SWITCH VIO WIRE W/ TIRE PRESSURE MONITORING UNIT WARNING/ INDICATOR LIGHTS WHT WIRE YEL WIRE
