Car Wiring Diagrams for Memory systems circuit for Mazda CX-3 I facelift (2018-2024)

BACK BLK WIRE BLU WIRE C-04 C-05 C-08 C-20 C-69 COMPUTER DATA LINES SYSTEM DOWN DRIVER-SIDE SEAT FRONT GRN WIRE HOT AT ALL TIMES HOT W/ INTERIOR FUSE LIFT MOTOR, POSITION SENSOR LT GRN WIRE METER 1 FUSE NCA WIRE POSITION MEMORY CONTROL MODULE RECLINER MOTOR, POSITION SENSOR RED WIRE RELAY & FUSE BLOCK SLIDER MOTOR, POSITION SENSOR TILT MOTOR, POSITION SENSOR WHT WIRE

BACK BACK-UP BLK WIRE C-20 DOWN DRIVER SIDE POWER SEAT SWITCH DRIVER-SIDE SEAT FRONT FUSE BLOCK HOT AT ALL TIMES LIFT LUMBAR LUMBAR SUPPORT MOTOR MEMORY NCA WIRE P SEAT (D) FUSE PNK WIRE POSITION MEMORY SWITCH RECLINER SET- SLIDE TILT UP DOWN
