Mazda CX-3 I facelift (2018-2024) steering warmer control unit Wiring diagram
This page shows the only wiring diagram for the component.steering warmer control unit, which is found in the car Mazda CX-3 I facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering warmer control unit (1 of 1)
0616-101
0616-102
0921-301
ACCESSORY SOCKET
AUDIO AMPLIFIER SHIELD
AUDIO UNIT
AUDIO UNIT SHIELD
AUXILIARY JACK/ USB PORT/ SD CARD SLOT HUB
AUXILIARY JACK/ USB PORT/ SD CARD SLOT HUB SHIELD
AWD CONTROL MODULE
BLK WIRE
BLOWER FAN CONTROLLER
BLUETOOTH UNIT
BRAKE SWITCH
C-09
C-16
C-18
C-22
C-25
C-54
CD PLAYER
CD PLAYER SHIELD
CENTER DISPLAY
CLIMATE CONTROL UNIT
CLOCKSPRING
COMMANDER SWITCH
CONNECTIVITY MASTER UNIT
CONNECTIVITY MASTER UNIT SHIELD
FAN SWITCH
J/C C-44
J/C C-66
LF CONTROL UNIT
MANUAL A/C
MICROPHONE SHIELD
NCA WIRE
RIGHT DOOR LOCK SWITCH
RIGHT END OF DASH)
RIGHT FRONT DOOR LATCH, LOCK ACTUATOR
RIGHT FRONT OUTER HANDLE
RIGHT REAR DOOR LATCH, LOCK ACTUATOR
STEERING WARMER CONTROL UNIT
TUNER, AMP UNIT
TUNER, AMP UNIT SHIELD
W/O BOSE W/ BOSE
WIRELESS CHARGER
Go to component -> Ground distribution circuit (1 of 4) -> STEERING WARMER CONTROL UNIT
