Car Wiring Diagrams for Charging circuit for Mazda CX-3 I (2015-2018)

BATTERY BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM GENERATOR GRN WIRE INSTRUMENT CLUSTER J/C C-35 LT BLU WIRE LT GRN WIRE MAIN FUSE METER 1 FUSE MICROCOMPUTER PCM RELAY & FUSE BLOCK RELAY ENERGIZED STARTER STR FUSE VIO WIRE WARNING/ INDICATOR LIGHTS WHT WIRE
