Radio circuit, w/o bose w/ navigation for Mazda CX-3 I (2015-2018)

Radio circuit, w/o bose w/ navigation (1 of 4)

CX-3 Mazda I (2015-2018): Radio circuit, w/o bose w/ navigation (1 of 4)

Get access

0920-218 AUXILIARY JACK/USB PORT/SD CARD SLOT HUB BLK WIRE BLU WIRE BRN WIRE C-08 C-12 C-13 COMPUTER DATA LINES SYSTEM CONNECTIVITY MASTER UNIT FUSE BLOCK GPS ANTENNA GRN WIRE HOT W/ ACC RELAY ENERGIZED J/C C-44 LT BLU WIRE LT GRN WIRE MICROPHONE MIRROR FUSE NCA WIRE PNK WIRE RED WIRE VIO WIRE WHT WIRE YEL WIRE

Radio circuit, w/o bose w/ navigation (2 of 4)

CX-3 Mazda I (2015-2018): Radio circuit, w/o bose w/ navigation (2 of 4)

Get access

0922-201 0922-202 AUDIO 2 FUSE BLK WIRE BLU WIRE BRN WIRE C-04 C-10 CLOCK- SPRING DOWN GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACC RELAY ENERGIZED HUNG-UP INFO INTERIOR FUSE LT BLU WIRE LT GRN WIRE NCA WIRE PICK-UP PNK WIRE RADIO FUSE RED WIRE RELAY & FUSE BLOCK SEEK STEERING SWITCH TALK VIO WIRE VOL (-) WHT WIRE

Radio circuit, w/o bose w/ navigation (3 of 4)

CX-3 Mazda I (2015-2018): Radio circuit, w/o bose w/ navigation (3 of 4)

Get access

BLK WIRE BLU WIRE BRN WIRE C-07 C-09 C-15 C-16 C-54 CD PLAYER CENTER DISPLAY COMMANDER SWITCH COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE INTERIOR LIGHTS J/C C-38 J/C C-39 J/C C-40 J/C C-41 J/C C-44 LEFT FRONT DOOR SPEAKER LEFT TWEETER LT BLU WIRE LT GRN WIRE NCA WIRE PNK WIRE RED WIRE RIGHT END OF DASH) RIGHT FRONT DOOR SPEAKER RIGHT TWEETER START STOP UNIT SYSTEM VIO WIRE WHT WIRE YEL WIRE

Radio circuit, w/o bose w/ navigation (4 of 4)

CX-3 Mazda I (2015-2018): Radio circuit, w/o bose w/ navigation (4 of 4)

Get access

0920-211 0920-212 0920-219 0920-220 ANTENNA AMPLIFIER BLK WIRE BLU WIRE BRN WIRE C-05 C-07 C-17 C-18 C-22 CENTER ROOF ANTENNA COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE INSTRUMENT CLUSTER LEFT REAR DOOR SPEAKER LT BLU WIRE LT GRN WIRE MICROCOMPUTER NCA WIRE RED WIRE RIGHT REAR DOOR SPEAKER TAN WIRE VIO WIRE W/ SIRIUS XM SATELLITE RADIO SYSTEM WHT WIRE YEL WIRE
