Navigation circuit, w/ bose for Mazda CX-3 I (2015-2018)

Navigation circuit, w/ bose (1 of 5)

CX-3 Mazda I (2015-2018): Navigation circuit, w/ bose (1 of 5)

Get access

0920-318 AUXILIARY JACK/USB PORT/SD CARD SLOT HUB BLK WIRE BLU WIRE BRN WIRE C-08 C-12 C-13 COMPUTER DATA LINES SYSTEM CONNECTIVITY MASTER UNIT FUSE BLOCK GPS ANTENNA GRN WIRE HOT W/ ACC RELAY ENERGIZED J/C C-44 LT BLU WIRE LT GRN WIRE MICROPHONE MIRROR FUSE NCA WIRE PNK WIRE RED WIRE VIO WIRE WHT WIRE YEL WIRE

Navigation circuit, w/ bose (2 of 5)

CX-3 Mazda I (2015-2018): Navigation circuit, w/ bose (2 of 5)

Get access

0922-201 0922-202 AUDIO 1 FUSE AUDIO 2 FUSE BLK WIRE BLU WIRE BRN WIRE C-04 CLOCK- SPRING DOWN GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACC RELAY ENERGIZED HUNG-UP INFO INTERIOR FUSE LT BLU WIRE LT GRN WIRE NCA WIRE PICK-UP PNK WIRE RADIO FUSE RED WIRE RELAY & FUSE BLOCK SEEK STEERING SWITCH TALK VIO WIRE VOL (-) WHT WIRE

Navigation circuit, w/ bose (3 of 5)

CX-3 Mazda I (2015-2018): Navigation circuit, w/ bose (3 of 5)

Get access

BLK WIRE BLU WIRE BRN WIRE C-18 C-54 CD PLAYER CENTER DISPLAY COMMANDER SWITCH COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE INTERIOR LIGHTS J/C C-44 LT BLU WIRE LT GRN WIRE NCA WIRE PNK WIRE RED WIRE RIGHT REAR DOOR SPEAKER START STOP UNIT SYSTEM VIO WIRE WHT WIRE YEL WIRE

Navigation circuit, w/ bose (4 of 5)

CX-3 Mazda I (2015-2018): Navigation circuit, w/ bose (4 of 5)

Get access

0920-311 0920-319 BLK WIRE BLU WIRE BRN WIRE C-05 C-07 C-10 C-15 C-17 C-22 COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE INSTRUMENT CLUSTER LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER LEFT TWEETER LT BLU WIRE LT GRN WIRE MICROCOMPUTER NCA WIRE PNK WIRE RED WIRE TAN WIRE VIO WIRE WHT WIRE YEL WIRE

Navigation circuit, w/ bose (5 of 5)

CX-3 Mazda I (2015-2018): Navigation circuit, w/ bose (5 of 5)

Get access

0920-311 0920-312 0920-321 ANTENNA AMPLIFIER AUDIO AMPLIFIER BASS BOX (LEFT SIDE OF CARGO AREA) BLK WIRE BLU WIRE BRN WIRE C-05 C-09 C-16 C-22 C-62 C-65 CENTER ROOF ANTENNA GRN WIRE GRY WIRE J/C C-44 J/C C-66 (RIGHT CENTER OF DASH) LT BLU WIRE LT GRN WIRE NCA WIRE PNK WIRE RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT TWEETER VIO WIRE W/ SIRIUS XM SATELLITE RADIO SYSTEM WHT WIRE YEL WIRE
