Mazda CX-3 I (2015-2018) selector lever component, hazard warning switch Wiring diagram
This page shows the only wiring diagram for the component.selector lever component, hazard warning switch, which is found in the car Mazda CX-3 I (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram selector lever component, hazard warning switch (1 of 1)
BLK WIRE
BRN WIRE
DSC HU/CM
ELECTRIC VARIABLE VALVE TIMING MOTOR/DRIVER, IGNITION COILS 1, 2, 3, 4
EPS CONTROL MODULE
FAN CONTROL MODULE, WIPER INT RELAY, WINDSHIELD WIPER MOTOR
LIFTGATE LATCH, LOCK ACTUATOR, REAR WINDOW DEFOGGER, REAR WIPER MOTOR
SELECTOR LEVER COMPONENT, HAZARD WARNING SWITCH
W/ AIR INTAKE ACTUATOR
Go to component -> Ground distribution circuit (1 of 2) -> SELECTOR LEVER COMPONENT, HAZARD WARNING SWITCH
