Mazda CX-3 I (2015-2018) bsm switch Wiring diagrams
This page contains all the electrical diagrams for the component. bsm switch, in which he is found in the car Mazda CX-3 I (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram bsm switch (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
BSM SWITCH
C-04
C-08
C-09
C-15
C-16
CLUSTER SWITCH
COMPUTER DATA LINES SYSTEM
GRN WIRE
INDICATOR
INSTRUMENT CLUSTER
J/C C-35
J/C C-46
J/C C-47
LEFT BLIND SPOT MONITORING (BSM) CONTROL MODULE
LEFT BLIND SPOT MONITORING (BSM) WARNING LIGHT
LEFT POWER OUTER MIRROR
LIGHTS)
LT BLU WIRE
LT GRN WIRE
METER 1 FUSE
MICROCOMPUTER
NCA WIRE
PNK C-15 WIRE
PNK WIRE
RED WIRE
RELAY & FUSE BLOCK
RELAY ENERGIZED
RIGHT BLIND SPOT MONITORING (BSM) CONTROL MODULE
RIGHT BLIND SPOT MONITORING (BSM) WARNING LIGHT
RIGHT POWER OUTER MIRROR
VIO WIRE
WARNING
Go to component -> Blind spot monitoring circuit -> BSM SWITCH
Wiring diagram bsm switch (2 of 2)
BCM
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SENSOR
BSM SWITCH
C-15
C-16
C-17
C-18
CLUSTER SWITCH
COMPUTER DATA LINES SYSTEM
FUEL GAUGE SENDER UNIT (SUB)
FUEL PUMP UNIT/ FUEL GAUGE SENDER UNIT
GRN WIRE
GRY WIRE
INDICATOR UNIT
LDWS SWITCH
LEFT FRONT DOOR LATCH, LOCK ACTUATOR
LEFT REAR DOOR LATCH, LOCK ACTUATOR
LT GRN WIRE
OIL PRESSURE SWITCH
PCM
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT DOOR LATCH, LOCK ACTUATOR
RIGHT REAR DOOR LATCH, LOCK ACTUATOR
SCBS OFF SWITCH
SEATS SYSTEM
TAN WIRE
TCS OFF SWITCH
TPMS SET SWITCH
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> BSM SWITCH
