2.5l, a/t circuit for Mazda 626 GF (1997-2002)

3-2 TIMING SOL SHIFT SOL BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/YEL WIRE CHECK ENG IND DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH) DIODE (LEFT SIDE OF DASH) EGI INJ ENGINE CONTROL SYSTEM (FUEL INJ) ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR (TOP FRONT OF ENGINE) GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION SWITCH INSTRUMENT CLUSTER SYSTEM JC-01 JC-03 (CENTER OF DASH) JOINT BOX (BEHIND LEFT SIDE OF DASH) ENGINE FUSE LOCK OFF LT GRN/BLK WIRE LT GRN/RED WIRE MAIN FUSE BLOCK (ON LEFT FRONT INNER FENDER PANEL) MAIN RELAY METER FUSE NOISE FILTER (TOP OF BRAKE PEDAL) O/D OFF IND O/D OFF SWITCH ORG/ WIRE ORG/BLU WIRE PNK WIRE POWERTRAIN CONTROL MODULE (UNDER CENTER CONSOLE) PRES- SURE CNTRL SOL RED WIRE RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE ROOM FUSE RUN WIRE SHIFT SOL SHIFT SOL TCC SOL SOLENOID VALVE (EC-AT) (IN TRANSAXLE) SPEEDO- METER STARTER STOP FUSE THROTTLE POSITION SENSOR (ON THROTTLE BODY ASSEMBLY) TRANSAXLE FLUID TEMP SENSOR INPUT/TURBINE SPEED SENSOR (LEFT FRONT OF TRANSAXLE) TRANSAXLE RANGE SWITCH VEHICLE SPEED SENSOR (LEFT SIDE OF ENG COMPT, ON TRANSAXLE) VIO WIRE VIO/YEL WIRE WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE
