Mazda 626 GF (1997-2002) Anti-lock brake circuits

A/B, ABS FUSE AA AB AC AD AE ABS FUSE ABS FUSE ABS FUSE ABS IND. ABS WHEEL SPEED SENSORS (ON EACH WHEEL HUB/SPINDLE ASSEMBLY) ABS/TCS CONTROL MODULE (ON LEFT SIDE OF ENGINE COMPARTMENT) BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRAKE SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) BRN WIRE BRN/WHT WIRE CRUISE CONTROL SYSTEM DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) ENGINE CONTROLS SYSTEM GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN RUN, START INSTRUMENT CLUSTER JC-01 (BEHIND LEFT HEADLIGHT) JOINT BOX (BEHIND LEFT SIDE OF DASH) LEFT FRONT LEFT REAR MAIN FUSE BOX (LEFT FRONT INNER FENDER PANEL) METER FUSE MICRO COMPUTER NOISE FILTER (BEHIND LEFT SIDE OF DASH) ORG/ WIRE ORG/BLK WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE POWERTRAIN CONTROL MODULE (UNDER CENTER CONSOLE) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE RIGHT FRONT RIGHT REAR STOP FUSE TCS IND TCS OFF IND TCS OFF SWITCH VIO WIRE W/O TCS WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE
