Mazda 626 GF (1997-2002) lock ignition switch wiring diagram
This page shows the only wiring diagram for the component.lock ignition switch, which is found in the car Mazda 626 GF (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
lock ignition switch wiring diagram (1 of 1)
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
CHARGE INDICATOR
EGI INJ FUSE
GENERATOR
IG KEY FUSE
INSTRUMENT CLUSTER
JOINT BOX (BEHIND LEFT SIDE OF DASH)
LOCK IGNITION SWITCH
MAIN FUSE
MAIN FUSE BLOCK (LEFT FRONT INNER FENDER PANEL)
METER FUSE
NCA WIRE
OFF
RUN WIRE
STARTER
WHT/BLK WIRE
WHT/GRN WIRE
YEL/RED WIRE
