Mazda 626 GE (1991-1997) right rear power window subswitch Wiring diagram
This page shows the only wiring diagram for the component.right rear power window subswitch, which is found in the car Mazda 626 GE (1991-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear power window subswitch (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU WIRE
CLOSE
CLOSE OPEN
GRN WIRE
HOT IN RUN POWER WINDOW FUSE 11
JC-05 (LEFT FRONT SIDE OF TRUNK)
JOINT BOX
LEFT FRONT POWER WINDOW REGULATOR CLOSE
LEFT REAR POWER WINDOW REGULATOR CLOSE
LEFT REAR POWER WINDOW SUBSWITCH
OPEN CLOSE
POWER WINDOW MAIN SWITCH ASSEMBLY
POWER-CUT SWITCH
RED WIRE
RIGHT FRONT POWER WINDOW REGULATOR CLOSE
RIGHT FRONT POWER WINDOW SUBSWITCH
RIGHT REAR POWER WINDOW REGULATOR CLOSE
RIGHT REAR POWER WINDOW SUBSWITCH
WHT WIRE
YEL WIRE
Go to component -> Power window circuit -> RIGHT REAR POWER WINDOW SUBSWITCH
