Power top/sunroof circuit for Mazda 6 GJ facelift (2015-2018)
Power top/sunroof circuit
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
C-05
C-08
C-11
CLOSE
COMPUTER
COMPUTER DATA LINES SYSTEM
FUSE BLOCK
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
MICRO -
RELAY & FUSE BLOCK
RELAY ENERGIZED
SOUND SYSTEMS
SUNROOF FUSE
SUNROOF MOTOR (CENTER FRONT OF ROOF)
SUNROOF RELAY 1
SUNROOF RELAY 2
SUNROOF SWITCH
TILT UP
VIO WIRE
VIO/RED WIRE
VIO/WHT WIRE
