Memory systems circuit for Mazda 6 GJ facelift (2015-2018)

BACK BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE C-03 C-09 C-19 COMPUTER DATA LINES SYSTEM DOWN FRONT GRN/BLK WIRE HOT AT ALL TIMES HOT W/ LIFT MOTOR, POSITION SENSOR METER 1 FUSE NCA WIRE POSITION MEMORY CONTROL MODULE RECLINER MOTOR, POSITION SENSOR RED WIRE RELAY & FUSE BLOCK ROOM FUSE SLIDER MOTOR, POSITION SENSOR TILT MOTOR, POSITION SENSOR WHT WIRE

BACK BACK-UP C-19 DOWN DRIVER SIDE POWER SEAT SWITCH FRONT FUSE BLOCK GRN/YEL WIRE HOT AT ALL TIMES LIFT SWITCH LUMBAR SUPPORT MOTOR LUMBAR SWITCH MEMORY NCA WIRE P SEAT (D) FUSE POSITION MEMORY SWITCH RECLINER SWITCH SET- SLIDE SWITCH TILT SWITCH UP DOWN
