Ground distribution circuit for Mazda 6 GJ facelift (2015-2018)
Ground distribution circuit (1 of 2)
ACC RELAY, DRL RELAY (W/O LED))
ACTIVE AIR SHUTTER (W/ I-ELOOP), LEFT FRONT FOG LIGHT, RIGHT FRONT FOG LIGHT
AUXILIARY JACK/USB PORT (W/O BOSE),
BATTERY
BLK WIRE
BLK/GRY WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER FAN CONTROLLER
BRN WIRE
CD PLAYER, CD PLAYER SHIELD (W/O BOSE), BLUETOOTH UNIT,
DATA LINK CONNECTOR 2, INDICATOR UNIT,
FBCM, TCM, RELAY & FUSE BLOCK (COOLING FAN RELAY 2) & COOLING FAN MOTOR 2
LASER SENSOR (W/ SMART CITY BRAKE SUPPORT (SCBS)),
LEFT FRONT COMBINATION LIGHT
LEFT SIGNATURE WING ILLUMINATION, DSC HU/CM,
M/T
W/ STEERING SHIFT SWITCH
Ground distribution circuit (2 of 2)
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
DRIVER SIDE SEAT WARMER UNIT (W/ SEAT CUSHION SIDE),
ELECTRIC PARKING BRAKE CONTROL MODULE
EPS CONTROL MODULE
FUEL PUMP UNIT SHIELD, HIGH-MOUNT BRAKE LIGHT, FUEL PUMP CONTROL MODULE
LEFT "C" PILLAR)
LEFT POWER OUTER MIRROR
POWER WINDOW MAIN SWITCH/POWER OUTER
REAR WINDOW DEFOGGER
RIGHT REAR POWER WINDOW SUB SWITCH, KEYLESS RECEIVER
TRUNK LID LATCH, RELEASE ACTUATOR, RBCM
W/ BLIND SPOT MONITORING
W/ I-ELOOP
W/ POWER SEAT
