Mazda 6 GJ facelift (2015-2018) trunk lid latch, release actuator, rbcm Wiring diagram
This page shows the only wiring diagram for the component.trunk lid latch, release actuator, rbcm, which is found in the car Mazda 6 GJ facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trunk lid latch, release actuator, rbcm (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
DRIVER SIDE SEAT WARMER UNIT (W/ SEAT CUSHION SIDE),
ELECTRIC PARKING BRAKE CONTROL MODULE
EPS CONTROL MODULE
FUEL PUMP UNIT SHIELD, HIGH-MOUNT BRAKE LIGHT, FUEL PUMP CONTROL MODULE
LEFT "C" PILLAR)
LEFT POWER OUTER MIRROR
POWER WINDOW MAIN SWITCH/POWER OUTER
REAR WINDOW DEFOGGER
RIGHT REAR POWER WINDOW SUB SWITCH, KEYLESS RECEIVER
TRUNK LID LATCH, RELEASE ACTUATOR, RBCM
W/ BLIND SPOT MONITORING
W/ I-ELOOP
W/ POWER SEAT
Go to component -> Ground distribution circuit (2 of 2) -> TRUNK LID LATCH, RELEASE ACTUATOR, RBCM
