Mazda 6 GJ facelift (2015-2018) left taillight/ rear side marker light Wiring diagram
This page shows the only wiring diagram for the component.left taillight/ rear side marker light, which is found in the car Mazda 6 GJ facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left taillight/ rear side marker light (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRAKE LIGHT
C-04
C-14
C-15
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/BLU WIRE
HAZARD WARNING SWITCH
LEFT "C" PILLAR)
LEFT POWER OUTER MIRROR
LEFT REAR COMBINATION LIGHT
LEFT REAR COMBINATION LIGHTS
LEFT REAR SIDE MARKER LIGHT
LEFT REAR TURN LIGHT
LEFT SIDE TURN LIGHT
LEFT TAILLIGHT/ REAR SIDE MARKER LIGHT
LT GRN/BLK WIRE
NCA WIRE
PNK/BLK WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT REAR COMBINATION LIGHT
RIGHT REAR COMBINATION LIGHTS
RIGHT REAR SIDE MARKER LIGHT
RIGHT TAILLIGHT/ REAR SIDE MARKER LIGHT
TAILLIGHT
W/ LED
W/O LED
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL/GRN WIRE
Go to component -> Exterior lamps circuit (2 of 3) -> LEFT TAILLIGHT/ REAR SIDE MARKER LIGHT
