Ground distribution circuit for Mazda 6 GJ facelift 2 (2018-2024)
Ground distribution circuit (1 of 2)
2.5L
BLK WIRE
BRN WIRE
CLIMATE CONTROL UNIT, BLOWER FAN CONTROLLER, ACCESSORY SOCKET
DRIVER SIDE SEAT VENTILATION UNIT
FAN CONTROL MODULE 1, FAN CONTROL MODULE 2,
IGNITION COIL 3 IGNITION COIL 4
LEFT HEADLIGHT LEVELING ACTUATOR
LEFT SWIVEL ACTUATOR,
M/T
PASSENGER SIDE SEAT VENTILATION UNIT
RELAY BOX (COOLING FAN RELAY 2), COOLING FAN MOTOR 2
RIGHT HEADLIGHT LEVELING ACTUATOR
RIGHT SWIVEL ACTUATOR,
STARTER INTERLOCK SWITCH (M/T), RELAY & FUSE BLOCK (FUEL INJECTOR RELAY),
Ground distribution circuit (2 of 2)
BATTERY
BLK WIRE
BLK/GRY WIRE
BRN WIRE
ELECTRIC PARKING BRAKE CONTROL MODULE
EPS CONTROL MODULE
KEYLESS RECEIVER, HIGH-MOUNT BRAKE LIGHT, RIGHT REAR POWER WINDOW SUB SWITCH
LEFT "C" PILLAR)
LEFT FRONT STRUT TOWER)
NCA WIRE
REAR WINDOW DEFOGGER
RIGHT DOOR LOCK SWITCH
RIGHT END OF DASH)
WASHER MOTOR, WINDSHIELD WIPER DE-ICER
