Mazda 6 GJ facelift 2 (2018-2024) windshield wiper de-icer Wiring diagram
This page shows the only wiring diagram for the component.windshield wiper de-icer, which is found in the car Mazda 6 GJ facelift 2 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield wiper de-icer (1 of 1)
0912-103
BLK WIRE
BLU WIRE
BRN WIRE
C-03
C-15
C-16
CAN L
CLIMATE CONTROL UNIT
COMPUTER DATA LINES SYSTEM
CONDENSER (LEFT "C" PILLAR)
DEFOG FUSE
FBCM
FUSE BLOCK
GRY WIRE
HOT AT ALL TIMES
LEFT HEATED OUTER MIRROR
LEFT POWER OUTER MIRROR
M DEF FUSE
MS CAN-H
MS CAN-L
NCA WIRE
PNK WIRE
R DEF RLY
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER RELAY
RED WIRE
RELAY & FUSE BLOCK
RIGHT HEATED OUTER MIRROR
RIGHT POWER OUTER MIRROR
VIO WIRE
WHT WIRE
WINDSHIELD WIPER DE-ICER
WINDSHIELD WIPER DE-ICER RELAY
WIPER DEI FUSE
Go to component -> Defoggers circuit -> WINDSHIELD WIPER DE-ICER
