Mazda 6 GJ facelift 2 (2018-2024) usb fuse wiring diagram
This page shows the only wiring diagram for the component.usb fuse, which is found in the car Mazda 6 GJ facelift 2 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
usb fuse wiring diagram (1 of 1)
A/C FUSE
ACCESSORY SOCKET
ADD FAN GE FUSE
AT IND FUSE
AUDIO 1 FUSE
AUDIO 3 FUSE
AUDIO FUSE
BLK WIRE
BLU WIRE
BODY COMPUTER, ANTI-THEFT, DOOR LOCKS, WIPER/WASHER SYSTEMS
BODY COMPUTER, WIPER/WASHER SYSTEMS
BRN WIRE
C-04
C-10
C-57
C-61
COOLING FANS SYSTEM
DEFOG FUSE
FAN GE FUSE
FROM HEATER FUSE (DIAGRAM 1 OF 3)
FROM RELAY & FUSE BLOCK (DIAGRAM 3 OF 3)
FUSE BLOCK
GRN WIRE
GRY WIRE
HAZARD FUSE
HEADLIGHTS, AIR CONDITIONING SYSTEMS
HORN FUSE
HORN RELAY
LEFT "C" PILLAR)
LT GRN WIRE
MIRROR FUSE
NCA WIRE
OUTLET FUSE
PNK WIRE
POWER WINDOWS, DOOR LOCKS, NAVIGATION, MIRRORS, SOUND SYSTEMS
R OUTLET 2 FUSE
R WIPER FUSE
REAR WINDOW DEFOGGER RELAY
RED WIRE
RELAY & FUSE BLOCK
SEATS SYSTEM
SHIFT INTERLOCK SYSTEM
SOUND SYSTEM
ST HEATER FUSE
STOP FUSE
TAIL FUSE
TNS RELAY (TAIL)
USB FUSE
USB POWER OUTLET (REAR SEAT)
VIO WIRE
WHT WIRE
WINDSHIELD WIPER DE-ICER RELAY
WIPER DEI FUSE
WIPER FUSE
YEL WIRE
Go to component -> Power distribution circuit (2 of 3) -> USB FUSE
