Mazda 6 GJ facelift 2 (2018-2024) right rear marker light Wiring diagram
This page shows the only wiring diagram for the component.right rear marker light, which is found in the car Mazda 6 GJ facelift 2 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear marker light (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
C-04
C-06
C-14
C-21
CAN L
COMPUTER DATA LINES SYSTEM
J/C C-01
LEFT BRAKE LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT TURN LIGHT
LEFT LICENSE PLATE LIGHT
LEFT PARKING LIGHT
LEFT REAR COMBINATION LIGHT
LEFT REAR MARKER LIGHT
LEFT REAR TURN LIGHT
LEFT TAILLIGHT
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PNK WIRE
RBCM
RED WIRE
RIGHT BRAKE LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT PARKING LIGHT
RIGHT REAR COMBINATION LIGHT
RIGHT REAR MARKER LIGHT
RIGHT REAR TURN LIGHT
RIGHT TAILLIGHT
STOP LP CTRL
STOP LP IN
STOP SW
VIO WIRE
W/ AFS
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (3 of 3) -> RIGHT REAR MARKER LIGHT
