Mazda 6 GJ facelift 2 (2018-2024) occupant classification sensor Wiring diagram
This page shows the only wiring diagram for the component.occupant classification sensor, which is found in the car Mazda 6 GJ facelift 2 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram occupant classification sensor (1 of 1)
0810-102
0810-104
ACL
BLK WIRE
BLU WIRE
C-10
C-20
CLOCK- SPRING
COMPUTER DATA LINES SYSTEM
CZ+
FID+
FIP+
GRY WIRE
INFLATOR 1
INFLATOR 2
INFLATOR DRIVER SIDE LAP PRE-TENSIONER SEAT BELT
INFLATOR PASSENGER SIDE LAP PRE-TENSIONER SEAT BELT
LT GRN WIRE
NCA WIRE
OCCUPANT CLASSIFICATION SENSOR
OCCUPANT CLASSIFICATION SENSOR CONTROL MODULE
RED WIRE
SAS CONTROL MODULE
SHORT BAR
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> OCCUPANT CLASSIFICATION SENSOR
