Mazda 6 GJ facelift 2 (2018-2024) left swivel actuator, Wiring diagram
This page shows the only wiring diagram for the component.left swivel actuator,, which is found in the car Mazda 6 GJ facelift 2 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left swivel actuator, (1 of 1)
2.5L
BLK WIRE
BRN WIRE
CLIMATE CONTROL UNIT, BLOWER FAN CONTROLLER, ACCESSORY SOCKET
DRIVER SIDE SEAT VENTILATION UNIT
FAN CONTROL MODULE 1, FAN CONTROL MODULE 2,
IGNITION COIL 3 IGNITION COIL 4
LEFT HEADLIGHT LEVELING ACTUATOR
LEFT SWIVEL ACTUATOR,
M/T
PASSENGER SIDE SEAT VENTILATION UNIT
RELAY BOX (COOLING FAN RELAY 2), COOLING FAN MOTOR 2
RIGHT HEADLIGHT LEVELING ACTUATOR
RIGHT SWIVEL ACTUATOR,
STARTER INTERLOCK SWITCH (M/T), RELAY & FUSE BLOCK (FUEL INJECTOR RELAY),
Go to component -> Ground distribution circuit (1 of 2) -> LEFT SWIVEL ACTUATOR,
