Mazda 6 GJ facelift 2 (2018-2024) keyless receiver, high-mount brake light, right rear power window sub switch Wiring diagram
This page shows the only wiring diagram for the component.keyless receiver, high-mount brake light, right rear power window sub switch, which is found in the car Mazda 6 GJ facelift 2 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram keyless receiver, high-mount brake light, right rear power window sub switch (1 of 1)
BATTERY
BLK WIRE
BLK/GRY WIRE
BRN WIRE
ELECTRIC PARKING BRAKE CONTROL MODULE
EPS CONTROL MODULE
KEYLESS RECEIVER, HIGH-MOUNT BRAKE LIGHT, RIGHT REAR POWER WINDOW SUB SWITCH
LEFT "C" PILLAR)
LEFT FRONT STRUT TOWER)
NCA WIRE
REAR WINDOW DEFOGGER
RIGHT DOOR LOCK SWITCH
RIGHT END OF DASH)
WASHER MOTOR, WINDSHIELD WIPER DE-ICER
Go to component -> Ground distribution circuit (2 of 2) -> KEYLESS RECEIVER, HIGH-MOUNT BRAKE LIGHT, RIGHT REAR POWER WINDOW SUB SWITCH
