Mazda 6 GJ facelift 2 (2018-2024) electric variable valve timing motor/driver Wiring diagrams

ALTF BLK WIRE BLU WIRE BRN WIRE CMP EX CMP IN ELECTRIC VARIABLE VALVE TIMING MOTOR/DRIVER ENGINE MAIN RELAY ENGINE OIL SOLENOID VALVE ETCN ETCP GRN WIRE GRY WIRE IB 3 IB 4 LT BLU WIRE LT GRN WIRE OCV FOR 1 CYLINDER DEACTIVATION OCV FOR 4 CYLINDER DEACTIVATION OCV FOR HYDRAULIC VARIABLE VALVE TIMING SYSTEM OCV HYD OIL CONTROL VALVE OILPSOL/OCV OP PCM (LEFT REAR OF ENGINE COMPT) PNK WIRE PURGE SOLENOID VALVE RED WIRE STARTING/ CHARGING SYSTEM TAN WIRE UEGOH VIO WIRE VTD VTP VTS WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE C-01 C-05 COOLING FAN, NAVIGATION SYSTEMS ELECTRIC VARIABLE VALVE TIMING (EVVT) RELAY ELECTRIC VARIABLE VALVE TIMING MOTOR/DRIVER ENG MAIN FUSE ENGINE 1 FUSE ENGINE 2 FUSE ENGINE 3 FUSE EVVT FUSE FUEL INJECTOR RELAY FUEL PUMP CONTROL MODULE FUEL PUMP FUEL PUMP UNIT GRN WIRE GRY WIRE HOT AT ALL TIMES INJECTOR FUSE J/C C-62 LEFT "C" PILLAR) LT BLU WIRE MAIN RELAY (ENG MAIN) NCA WIRE PNK WIRE RED WIRE RELAY & FUSE BLOCK TAN WIRE VIO WIRE WHT WIRE YEL WIRE
