Mazda 6 GJ facelift 2 (2018-2024) center rear occupancy sensor Wiring diagram
This page shows the only wiring diagram for the component.center rear occupancy sensor, which is found in the car Mazda 6 GJ facelift 2 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center rear occupancy sensor (1 of 1)
0810-202
0810-203
BLK WIRE
BLU WIRE
C-03
C-10
C-61
CAN L
CENTER REAR BUCKLE SWITCH
CENTER REAR OCCUPANCY SENSOR
COMPUTER DATA LINES SYSTEM
GRN WIRE
J/C C-25
J/C C-28
LEFT "C" PILLAR)
LEFT REAR BUCKLE SWITCH
LEFT REAR OCCUPANCY SENSOR
LT BLU WIRE
METER 1 FUSE
NCA WIRE
PNK WIRE
RBCM
REAR SEAT BELT REMINDER UNIT
REAR SEAT)
RELAY & FUSE BLOCK
RELAY 1 ENERGIZED
RIGHT END OF DASH)
RIGHT REAR BUCKLE SWITCH
RIGHT REAR OCCUPANCY SENSOR
SEAT BELT SWITCH CR
SEAT BELT SWITCH LR
SEAT BELT SWITCH RR
TAN WIRE
WHT WIRE
Go to component -> Rear seat belt reminder circuit -> CENTER REAR OCCUPANCY SENSOR
