Mazda 6 GJ facelift 2 (2018-2024) auto lo off mist hi Wiring diagram
This page shows the only wiring diagram for the component.auto lo off mist hi, which is found in the car Mazda 6 GJ facelift 2 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto lo off mist hi (1 of 1)
2.5L
AS SW WASHER FLUID LVL SW
AUTO LO OFF MIST HI
AUTO STOP SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
C-03
C-11
C-27
CAN-H- CAN-L-
CIRCUIT BREAKER
COMPUTER DATA LINES SYSTEM
F WIP LOW SW
FBCM
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HUMIDITY SENSOR/ AUTO LIGHT SENSOR/RAIN SENSOR
INSTRUMENT CLUSTER
J/C C-28 (CENTER OF DASH)
LIN (RLS)
LT GRN WIRE
METER 1 FUSE
MICROCOMPUTER
NCA WIRE
PNK WIRE
RED WIRE
RELAY & FUSE BLOCK
RELAY 1 ENERGIZED
RELAY 2 ENERGIZED
START STOP UNIT (LOWER LEFT SIDE OF DASH)
VIO WIRE
WARNING/ INDICATOR LIGHTS
WASHER FLUID LEVEL SENSOR
WASHER MOTOR
WASHER MTR R
WHT WIRE
WINDSHIELD WASHER SWITCH
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER/ WASHER SWITCH
WIPER FUSE
YEL WIRE
Go to component -> Wiper/washer circuit -> AUTO LO OFF MIST HI
