Computer data lines circuit for Mazda 6 GJ (2012-2015)

2.5L 3.7L A/T AF C-05 AUDIO UNIT (W/O BOSE AUDIO) AUDIO UNIT/ CAR-NAVIGATION UNIT (W/ BOSE AUDIO) BCM (BEHIND LEFT KICK PANEL) BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLUETOOTH UNIT (IF EQUIPPED) (RIGHT END OF DASH) C-02 C-06 M/T C-27 CHECK CONNECTOR (ENGINE COMPARTMENT) (IN MAIN FUSE, RELAY BOX) CLIMATE CONTROL MODULE (AUTOMATIC A/C) (LOWER CENTER OF DASH) DATA LINK CONNECTOR 2 (UNDER LOWER LEFT SIDE OF DASH) DSC HU/CM (IF EQUIPPED) (RIGHT REAR OF ENGINE COMPT) FUEL PUMP RELAY MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) FUSE BLOCK (UNDER LEFT SIDE OF DASH) GRN/ORG WIRE GRN/YEL WIRE GRY WIRE GRY/ORG WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT W/ IG 1 RELAY ENERGIZED HOT IN RUN OR START INFORMATION DISPLAY INSTRUMENT CLUSTER LEFT BSM CONTROL MODULE (LEFT REAR OF TRUNK) M/T ORG/ WIRE ORG/BLU WIRE PCM (LEFT REAR OF ENGINE COMPT) RIGHT BSM CONTROL MODULE (RIGHT REAR OF TRUNK) ROOM FUSE SAS CONTROL MODULE (UNDER FRONT OF CENTER CONSOLE) SAS FUSE SIRIUS SATELLITE RADIO UNIT (IF EQUIPPED) (RIGHT SIDE OF DASH) TCM (2.5L: LOWER LEFT SIDE OF DASH) (3.7L: REAR OF ENGINE) W/ REAR HARNESS 4 W/O REAR HARNESS 4 W/O BSM
