Mazda 6 GJ (2012-2015) w/ bluetooth w/ bluetooth, sirius satellite radio unit Wiring diagrams
This page contains all the electrical diagrams for the component. w/ bluetooth w/ bluetooth, sirius satellite radio unit, in which he is found in the car Mazda 6 GJ (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
w/ bluetooth w/ bluetooth, sirius satellite radio unit wiring diagram (1 of 2)
0920-318
0920-319
0920-320
ANTENNA AMPLIFIER ANTENNA
AUDIO UNIT/CAR-NAVIGATION UNIT (LOWER CENTER OF DASH)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BRN WIRE
C-10
C-35
C-61
C-62
C-63
NCA WIRE
ORG/BLK WIRE
REAR MOUNT CAMERA
RED WIRE
RED/WHT WIRE
W/ BLUETOOTH W/ BLUETOOTH, SIRIUS SATELLITE RADIO UNIT
W/O REAR MOUNT CAMERA/ W/ U-TURN CIRCUITS
WHT WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Navigation circuit, with bose (2 of 3) -> W/ BLUETOOTH W/ BLUETOOTH, SIRIUS SATELLITE RADIO UNIT
w/ bluetooth w/ bluetooth, sirius satellite radio unit wiring diagram (2 of 2)
0920-318
0920-319
0920-320
ANTENNA AMPLIFIER ANTENNA
AUDIO UNIT/CAR-NAVIGATION UNIT (LOWER CENTER OF DASH)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BRN WIRE
C-10
C-35
C-61
C-62
C-63
NCA WIRE
ORG/BLK WIRE
REAR MOUNT CAMERA
RED WIRE
RED/WHT WIRE
W/ BLUETOOTH W/ BLUETOOTH, SIRIUS SATELLITE RADIO UNIT
W/O REAR MOUNT CAMERA/ W/ U-TURN CIRCUITS
WHT WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Radio circuit, with bose (2 of 3) -> W/ BLUETOOTH W/ BLUETOOTH, SIRIUS SATELLITE RADIO UNIT
