Mazda 6 GJ (2012-2015) start system w/o advanced keyless entry and push button wiring diagram
This page shows the only wiring diagram for the component.start system w/o advanced keyless entry and push button, which is found in the car Mazda 6 GJ (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
start system w/o advanced keyless entry and push button wiring diagram (1 of 1)
BCM (BEHIND LEFT KICK PANEL)
BLK/BLU WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/ORG WIRE
BRN/YEL WIRE
DOOR LOCKS SYSTEM
FORWARD DOWN
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LIFT SWITCH UP
MEMORY 1
MEMORY 2
MEMORY 3
METER IG FUSE
NCA WIRE
ORG/ WIRE
ORG/BLU WIRE
ORG/YEL WIRE
POSITION MEMORY SWITCH
POWER SEAT SWITCH
POWER WINDOWS SYSTEM
RECLINER SWITCH BACKWARD
ROOM FUSE
SET-
SLIDE SWITCH BACKWARD FORWARD
START SYSTEM
START SYSTEM W/O ADVANCED KEYLESS ENTRY AND PUSH BUTTON
TILT SWITCH DOWN UP
VIO/BRN WIRE
W/ ADVANCED KEYLESS ENTRY AND PUSH BUTTON
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Memory systems circuit (2 of 2) -> START SYSTEM W/O ADVANCED KEYLESS ENTRY AND PUSH BUTTON
