Mazda 6 GJ (2012-2015) right brake/ taillight light Wiring diagram
This page shows the only wiring diagram for the component.right brake/ taillight light, which is found in the car Mazda 6 GJ (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right brake/ taillight light (1 of 1)
2.5L
3.7L
AA C-06
AUTO LIGHT/ WIPER CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
BCM (BEHIND LEFT KICK PANEL)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE BRAKE
BRAKE SWITCH (TOP OF BRAKE PEDAL)
BRAKE/
C-06
C-07
C-29 AO C-30
C-30 C-29
C-35
C-62
COMPUTER DATA LINES SYSTEM
DSC HU/CM (RIGHT REAR OF ENGINE COMPT)
EXCEPT LED LED TYPE TYPE
EXCEPT LED TYPE
GRN WIRE
GRN/RED WIRE
GRY/RED WIRE
GRY/VIO WIRE
HAZARD FUSE
HAZARD WARNING SWITCH
HEAD TNS AUTO LIGHT SWITCH
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
HOT AT ALL TIMES MAIN FUSE BLOCK STOP FUSE (LEFT SIDE OF ENGINE COMPT)
HOT IN ON OR START FUSE BLOCK (UNDER LEFT SIDE OF DASH)
INSTRUMENT CLUSTER
LEFT
LEFT BRAKE/ TAILLIGHT LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT LICENSE PLATE LIGHT
LEFT PARKING/ FRONT TURN LIGHT
LEFT REAR TURN LIGHT
LEFT TURN IND PANEL LIGHT CONTROL
METER IG FUSE
MICROCOMPUTER
NCA WIRE
OFF
ORG/ WIRE
ORG/GRN WIRE
PCM (LEFT REAR OF ENGINE COMPT)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/ORG WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT
RIGHT BRAKE/ TAILLIGHT LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT PARKING/ FRONT TURN LIGHT
RIGHT REAR TURN LIGHT
RIGHT TURN IND
SELECTOR IND DRIVE CIRCUIT
SELECTOR LEVER COMPONENT (A/T)
TAIL TAIL
TURN SIGNAL SWITCH
W/ REAR MOUNT CAMERA
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> RIGHT BRAKE/ TAILLIGHT LIGHT
