Mazda 6 GJ (2012-2015) rear door open Wiring diagram
This page shows the only wiring diagram for the component.rear door open, which is found in the car Mazda 6 GJ (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear door open (1 of 1)
AM AG
AN AF
AO C-06
AUTO
BCM (BEHIND LEFT KICK PANEL)
BLK WIRE
BLU WIRE
BRN WIRE
C-29
C-31
CLOSE
CLOSE RELAY
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
HALL EFFECT
HALL EFFECT SWITCH 2
HOT AT ALL TIMES
LEFT FRONT POWER WINDOW MOTOR (IN DRIVER'S DOOR)
LEFT REAR POWER WINDOW MOTOR (IN LEFT
LEFT REAR POWER WINDOW SUB SWITCH
MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
MAIN SWITCH
MANUAL
MEMORY SYSTEMS
OPEN CLOSE
OPEN MANUAL
OPEN RELAY
P WIND (D) FUSE
P/W CM
PNK WIRE
PNK/BLU WIRE
POWER WINDOW
POWER-CUT SWITCH
REAR DOOR OPEN
RED WIRE
SWITCH 1
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Power windows circuit, with driver side window auto open/close (1 of 2) -> REAR DOOR OPEN
