Mazda 6 GJ (2012-2015) panel light control Wiring diagram
This page shows the only wiring diagram for the component.panel light control, which is found in the car Mazda 6 GJ (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram panel light control (1 of 1)
AO C-30
BCM (BEHIND LEFT KICK PANEL)
BLK WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLU/RED WIRE
BSM OFF IND
BSM OFF SWITCH
C-10 (LEFT END OF DASH)
C-27
C-29 LEFT BSM INDICATOR LIGHT
COMPUTER DATA LINES SYSTEM
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/RED WIRE
HOT IN ON OR START FUSE BLOCK (UNDER LEFT SIDE OF DASH)
INSTRUMENT CLUSTER
LEFT BSM CONTROL MODULE (LEFT REAR OF TRUNK)
METER IG FUSE
MICROCOMPUTER
ORG/WHT WIRE
PANEL LIGHT CONTROL
RELAY ENERGIZED
RIGHT BSM CONTROL MODULE (RIGHT REAR OF TRUNK)
RIGHT BSM INDICATOR LIGHT
SELECTOR INDICATOR DRIVE CIRCUIT
WHT/BLK WIRE
WHT/RED WIRE
YEL/BLK WIRE
Go to component -> Blind spot monitoring circuit -> PANEL LIGHT CONTROL
