Mazda 6 GJ (2012-2015) off low int Wiring diagram
This page shows the only wiring diagram for the component.off low int, which is found in the car Mazda 6 GJ (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off low int (1 of 1)
AUTOSTOP SWITCH CIRCUIT BREAKER
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLU/RED WIRE
C-05
C-10
COMPUTER DATA LINES SYSTEM
FUSE
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRN/RED WIRE
GRN/WHT WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON
INSTRUMENT CLUSTER
INTERMITTENT RELAY
INTERMITTENT VOLUME
KEYLESS CONTROL MODULE
MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
METER IG FUSE
MICROCOMPUTER
MIST
OFF LOW HI INT
OFF LOW INT
PNK/ORG WIRE
PNK/YEL WIRE
RED WIRE
RED/BLU WIRE
RELAY BLOCK (LOWER LEFT SIDE OF DASH)
RELAY ENERGIZED HOT IN ON OR START
W/ ADVANCED KEYLESS ENTRY, PUSH BUTTON START SYSTEM
W/O ADVANCED KEYLESS ENTRY, PUSH BUTTON START SYSTEM
WASHER FLUID LEVEL SENSOR (IN WASHER FLUID RESERVOIR)
WASHER IND
WHT/BLK WIRE
WHT/GRN WIRE
WINDSHIELD WASHER MOTOR (ON WASHER FLUID RESERVOIR)
WINDSHIELD WASHER SWITCH
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER RELAY
WINDSHIELD WIPER/ WASHER SWITCH
WIPER FUSE
YEL WIRE
Go to component -> Wiper/washer circuit, without auto wiper system -> OFF LOW INT
