Mazda 6 GJ (2012-2015) mirrors, navigation, sound, instrument cluster systems Wiring diagram
This page shows the only wiring diagram for the component.mirrors, navigation, sound, instrument cluster systems, which is found in the car Mazda 6 GJ (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirrors, navigation, sound, instrument cluster systems (1 of 1)
2.5L
A/C FUSE
AIR CONDITIONING, DEFOGGER, POWER TOPS, SEATS, BODY COMPUTER SYSTEMS
ANTI-LOCK BRAKES, DOOR LOCKS, COMPUTER DATA LINES, COOLING FANS SYSTEMS
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
C-05
C-05 AN
C-55
D LOCK FUSE
DIODE
DOOR LOCKS, BODY COMPUTER SYSTEMS
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS, COOLING FANS SYSTEMS
ENGINE IG FUSE
FROM BTN FUSE (DIAGRAM 1 OF 2)
FRONT ACCESSORY SOCKET
FUSE BLOCK
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRN/YEL (OR GRN/BLU) WIRE
GRN/YEL WIRE
GRY/RED WIRE
HEGO FUSE
IGNITION SWITCH
INT LOCK/ SHIFT FUSE
METER IG FUSE
MIRROR FUSE
MIRRORS, NAVIGATION, SOUND, INSTRUMENT CLUSTER SYSTEMS
OFF
ORG/BLK WIRE
ORG/BLU WIRE
ORG/WHT WIRE
P OUTLET FUSE
P WIND FUSE
PNK/BLK WIRE
PNK/ORG WIRE
PNK/YEL WIRE
POWER WINDOWS SYSTEM
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
ROOM FUSE
RUN WIRE
SAS FUSE
SHIFT INTERLOCK SYSTEM
STARTING/ CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
WIPER FUSE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit, w/o advanced keyless entry & start system (2 of 2) -> MIRRORS, NAVIGATION, SOUND, INSTRUMENT CLUSTER SYSTEMS
