Mazda 6 GJ (2012-2015) ignition switch Wiring diagrams
This page contains all the electrical diagrams for the component. ignition switch, in which he is found in the car Mazda 6 GJ (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ignition switch (1 of 3)
2.5L
A/C FUSE HEGO FUSE
AN C-05
ANTI-LOCK BRAKES, DOOR LOCKS, COMPUTER DATA LINES, COOLING FANS SYSTEMS
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
C-05
C-55
DIODE
ENGINE CONTROLS, COOLING FANS SYSTEMS
ENGINE IG FUSE
FROM BTN FUSE (DIAGRAM 1 OF 2)
FRONT ACCESSORY
FUSE (DIAGRAM 1 OF 2)
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRN/YEL (OR GRN/BLU) WIRE
GRN/YEL WIRE
GRY/RED WIRE
IGNITION SWITCH
INT LOCK/ MIRROR FUSE SHIFT FUSE
METER IG FUSE
OFF
ORG/BLK WIRE
ORG/BLU WIRE
ORG/WHT WIRE
P OUTLET FUSE
P WIND FUSE
PNK/BLK WIRE
PNK/ORG WIRE
PNK/YEL WIRE
POWER WINDOWS SYSTEM
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
ROOM FUSE D LOCK FUSE
RUN WIRE
SAS FUSE
SHIFT MIRRORS, INTERLOCK NAVIGATION, SYSTEM SOUND, INSTRUMENT CLUSTER SYSTEMS
SOCKET
STARTING/ CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
WIPER FUSE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit, without advanced keyless entry & start system (2 of 2) -> IGNITION SWITCH
Wiring diagram ignition switch (2 of 3)
2.5L
A/C FUSE
AIR CONDITIONING, DEFOGGER, POWER TOPS, SEATS, BODY COMPUTER SYSTEMS
ANTI-LOCK BRAKES, DOOR LOCKS, COMPUTER DATA LINES, COOLING FANS SYSTEMS
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
C-05
C-05 AN
C-55
D LOCK FUSE
DIODE
DOOR LOCKS, BODY COMPUTER SYSTEMS
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS, COOLING FANS SYSTEMS
ENGINE IG FUSE
FROM BTN FUSE (DIAGRAM 1 OF 2)
FRONT ACCESSORY SOCKET
FUSE BLOCK
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRN/YEL (OR GRN/BLU) WIRE
GRN/YEL WIRE
GRY/RED WIRE
HEGO FUSE
IGNITION SWITCH
INT LOCK/ SHIFT FUSE
METER IG FUSE
MIRROR FUSE
MIRRORS, NAVIGATION, SOUND, INSTRUMENT CLUSTER SYSTEMS
OFF
ORG/BLK WIRE
ORG/BLU WIRE
ORG/WHT WIRE
P OUTLET FUSE
P WIND FUSE
PNK/BLK WIRE
PNK/ORG WIRE
PNK/YEL WIRE
POWER WINDOWS SYSTEM
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
ROOM FUSE
RUN WIRE
SAS FUSE
SHIFT INTERLOCK SYSTEM
STARTING/ CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
WIPER FUSE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit, w/o advanced keyless entry & start system (2 of 2) -> IGNITION SWITCH
Wiring diagram ignition switch (3 of 3)
2.5L
3.7L
A/T
BATTERY
BCM (BEHIND LEFT KICK PANEL)
BLK PNK/ WIRE
BLK/ YEL WIRE
BLK/BLU WIRE
BLK/PNK WIRE
BLK/YEL WIRE
BLU/BLK WIRE
C-02
C-05
C-06
C-13
FUSE
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRN/ORG WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/RED WIRE
HOLD
HOT IN ON OR START
IGNITION SWITCH
KEYLESS CONTROL MODULE (IF EQUIPPED) (BEHIND LEFT SIDE OF DASH)
M/T
MAIN FUSE
MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
METER IG FUSE
NCA WIRE
OFF
PCM (LEFT REAR OF ENGINE COMPT)
PNK/ BLK WIRE
PULL- IN
RED WIRE
RED/BLU WIRE
ST SIG FUSE
STARTER
STARTER INTERLOCK SWITCH (BEHIND LEFT SIDE OF DASH)
STARTER RELAY
STARTER RELAY 2 (3.7L)
TRANSAXLE
TRANSAXLE CONTROL MODULE
TRANSAXLE RANGE SWITCH (LEFT SIDE OF
VIO/YEL WIRE
YEL BLK/ WIRE
Go to component -> Starting circuit -> IGNITION SWITCH
