Mazda 6 GJ (2012-2015) grn/red Wiring diagrams
This page contains all the electrical diagrams for the component. grn/red, in which he is found in the car Mazda 6 GJ (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
grn/red wiring diagram (41 of 46)
AUTO DIMMING MIRROR (IN REAR VIEW MIRROR)
BCM (BEHIND LEFT KICK PANEL)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
C-21
C-22
C-29 AA
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRN/BLK WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
LEFT AUTO DIMMING OUTER MIRROR
METER IG FUSE
ORG/ WIRE
ORG/BLU WIRE
ORG/YEL WIRE
ROOM FUSE
W/ ADVANCED KEYLESS ENTRY, PUSH BUTTON START SYSTEM
W/O ADVANCED KEYLESS ENTRY, PUSH BUTTON START SYSTEM
YEL WIRE
YEL/BLU WIRE
Go to component -> Auto dimming mirror circuit, with auto dimming outer mirror -> GRN/RED WIRE
grn/red wiring diagram (42 of 46)
AUTO DIMMING MIRROR (IN REAR VIEW MIRROR)
BCM (BEHIND LEFT KICK PANEL)
BLK WIRE
C-21
C-22
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRN/BLK WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
HOT IN RUN OR START
METER IG FUSE
W/ ADVANCED KEYLESS ENTRY, PUSH BUTTON START SYSTEM
W/O ADVANCED KEYLESS ENTRY, PUSH BUTTON START SYSTEM
Go to component -> Auto dimming mirror circuit, without auto dimming outer mirror -> GRN/RED WIRE
grn/red wiring diagram (43 of 46)
AM AG
AN AF
AO C-06
AUTO
BCM (BEHIND LEFT KICK PANEL)
BLK WIRE
BLU WIRE
BRN WIRE
C-29
C-31
CLOSE
CLOSE RELAY
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
HALL EFFECT
HALL EFFECT SWITCH 2
HOT AT ALL TIMES
LEFT FRONT POWER WINDOW MOTOR (IN DRIVER'S DOOR)
LEFT REAR POWER WINDOW MOTOR (IN LEFT
LEFT REAR POWER WINDOW SUB SWITCH
MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
MAIN SWITCH
MANUAL
MEMORY SYSTEMS
OPEN CLOSE
OPEN MANUAL
OPEN RELAY
P WIND (D) FUSE
P/W CM
PNK WIRE
PNK/BLU WIRE
POWER WINDOW
POWER-CUT SWITCH
REAR DOOR OPEN
RED WIRE
SWITCH 1
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Power windows circuit, with driver side window auto open/close (1 of 2) -> GRN/RED WIRE
grn/red wiring diagram (44 of 46)
AN C-05
AP C-30 AG AF
BLK WIRE
BLU WIRE
BLU/RED WIRE
C-10
C-10 AF
C-32
CLOSE OPEN
COMPUTER DATA LINES SYSTEM
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IG KEY 1 FUSE
KEYLESS CONTROL
MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
MODULE (BEHIND LEFT SIDE OF DASH)
OPEN CLOSE
P WIND FUSE
PNK WIRE
PNK/BLU WIRE
POWER WINDOW RELAY
RED WIRE
RED/YEL WIRE
RELAY BLOCK (LOWER LEFT SIDE OF DASH)
RIGHT FRONT POWER WINDOW MOTOR (IN RIGHT FRONT DOOR)
RIGHT FRONT POWER WINDOW SUB SWITCH
RIGHT REAR POWER WINDOW MOTOR (IN RIGHT REAR DOOR)
RIGHT REAR POWER WINDOW SUB SWITCH
VIO WIRE
W/ ADVANCED KEYLESS ENTRY, PUSH BUTTON START SYSTEM
W/O ADVANCED KEYLESS ENTRY, PUSH BUTTON START SYSTEM
WHT WIRE
WHT/VIO WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Power windows circuit, with driver side window auto open/close (2 of 2) -> GRN/RED WIRE
grn/red wiring diagram (45 of 46)
AUTO LIGHT SENSOR/ RAIN SENSOR (ON BACK OF
AUTO LIGHT/WIPER CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
BCM (BEHIND LEFT KICK PANEL)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU RED/ WIRE
BLU/RED WIRE
C-05
C-10
C-11
C-21
COMPUTER DATA LINES SYSTEM
FUSE
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRN/RED WIRE
GRN/WHT WIRE
GRY/RED WIRE
H/L OFF TNS AUTO
HI AUTOSTOP SWITCH CIRCUIT LO BREAKER
HIGH LOW AUTO INT
HOT AT ALL TIMES
HOT IN ON
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
INTERMITTENT VOLUME
KEYLESS CONTROL MODULE
LIGHT SWITCH
MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
METER IG FUSE
MICROCOMPUTER
MIST
OFF
PNK/ORG WIRE
PNK/YEL WIRE
REAR VIEW MIRROR)
RED WIRE
RED/BLU WIRE
RELAY BLOCK (LOWER LEFT SIDE OF DASH)
RELAY ENERGIZED HOT IN ON OR START
W/ ADVANCED KEYLESS ENTRY, PUSH BUTTON START SYSTEM
W/O ADVANCED KEYLESS ENTRY, PUSH BUTTON START SYSTEM
WASHER FLUID LEVEL SENSOR (IN WASHER FLUID RESERVOIR)
WASHER IND
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WINDSHIELD GND WASHER SWITCH
WINDSHIELD WASHER MOTOR (ON WASHER FLUID RESERVOIR)
WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT)
WINDSHIELD WIPER RELAY
WINDSHIELD WIPER/ WASHER SWITCH
WIPER FUSE
YEL WIRE
Go to component -> Wiper/washer circuit, with auto wiper system -> GRN/RED WIRE
grn/red wiring diagram (46 of 46)
AUTOSTOP SWITCH CIRCUIT BREAKER
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLU/RED WIRE
C-05
C-10
COMPUTER DATA LINES SYSTEM
FUSE
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRN/RED WIRE
GRN/WHT WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON
INSTRUMENT CLUSTER
INTERMITTENT RELAY
INTERMITTENT VOLUME
KEYLESS CONTROL MODULE
MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
METER IG FUSE
MICROCOMPUTER
MIST
OFF LOW HI INT
OFF LOW INT
PNK/ORG WIRE
PNK/YEL WIRE
RED WIRE
RED/BLU WIRE
RELAY BLOCK (LOWER LEFT SIDE OF DASH)
RELAY ENERGIZED HOT IN ON OR START
W/ ADVANCED KEYLESS ENTRY, PUSH BUTTON START SYSTEM
W/O ADVANCED KEYLESS ENTRY, PUSH BUTTON START SYSTEM
WASHER FLUID LEVEL SENSOR (IN WASHER FLUID RESERVOIR)
WASHER IND
WHT/BLK WIRE
WHT/GRN WIRE
WINDSHIELD WASHER MOTOR (ON WASHER FLUID RESERVOIR)
WINDSHIELD WASHER SWITCH
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER RELAY
WINDSHIELD WIPER/ WASHER SWITCH
WIPER FUSE
YEL WIRE
Go to component -> Wiper/washer circuit, without auto wiper system -> GRN/RED WIRE
