Mazda 6 GJ (2012-2015) fan control module Wiring diagrams
This page contains all the electrical diagrams for the component. fan control module, in which he is found in the car Mazda 6 GJ (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
fan control module wiring diagram (1 of 3)
0112-02
0112-03
0740-203
0740-204
2.5L
2.5L ANTI-THEFT SYSTEM
3.7L
A/C FUSE
A/C RELAY
AIR INTAKE ACTUATOR (BEHIND RIGHT SIDE OF DASH)
BCM (BEHIND LEFT KICK PANEL)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLOWER FUSE
BLOWER RELAY (W/O REAR VENT) FRONT BLOWER RELAY (W/ REAR VENT)
BLU WIRE
BLU/ GRN WIRE
BRN WIRE
BRN/YEL WIRE
C-02
C-05
COLD
DIODE (LOWER LEFT SIDE OF DASH)
ENG IG FUSE
FAN CONTROL MODULE
FAN CONTROL MODULE RELAY
FAN FUSE
FRONT BLOWER MOTOR (UNDER RIGHT SIDE OF DASH)
FUSE BLOCK (UNDER LEFT SIDE OF DASH)
GRN WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT
HOT AT ALL TIMES
HOT IN RUN OR START
MAGNETIC CLUTCH (LEFT FRONT OF ENGINE)
MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
NCA WIRE
ORG/ WIRE
ORG/YEL WIRE
PASSENGER-SIDE AIR MIX ACTUATOR (RIGHT SIDE OF DASH)
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
PNK/ORG WIRE
PNK/YEL WIRE
RED WIRE
RED/YEL WIRE
RELAY ENERGIZED
SAS FUSE
W/ ADVANCED KEYLESS ENTRY, PUSH BUTTON START SYSTEM
W/ REAR VENT
W/O ADVANCED KEYLESS ENTRY, PUSH BUTTON START SYSTEM
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL GRN/ WIRE
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Automatic a/c circuit (3 of 3) -> FAN CONTROL MODULE
fan control module wiring diagram (2 of 3)
0112-02
0112-03
2.5L
2.5L 3.7L
3.7L
3.7L 2.5L
AV C-58 0140-237
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLU WIRE
BLU/GRY WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLU WIRE
C-05 DIODE ANTI-THEFT (LOWER SYSTEM LEFT SIDE OF DASH)
C-56
CHT SENSOR (RIGHT FRONT OF ENGINE)
COMPUTER DATA LINES SYSTEM
ENG IG SAS FUSE LEFT SIDE OF FUSE DASH)
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE SENSOR (LEFT REAR OF ENGINE COMPT)
FAN CONTROL MODULE
FAN CONTROL MODULE RELAY
FUSE BLOCK (UNDER
GRN WIRE
GRN/WHT WIRE
GRY/RED WIRE
HOT AT ALL TIMES MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) FAN FUSE
HOT IN RUN OR START
NCA WIRE
ORG/ WIRE
PCM (LEFT REAR OF ENGINE COMPT)
PUSH BUTTON START SYSTEM W/O ADVANCED KEYLESS ENTRY,
REFRIGERANT PRESSURE SENSOR (RIGHT FRONT OF ENGINE COMPT)
RELAY ENERGIZED
SENSOR GROUND
W/ ADVANCED KEYLESS ENTRY,
WHT WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> FAN CONTROL MODULE
fan control module wiring diagram (3 of 3)
