Mazda 6 GJ (2012-2015) exterior headlights lights system system Wiring diagram
This page shows the only wiring diagram for the component.exterior headlights lights system system, which is found in the car Mazda 6 GJ (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram exterior headlights lights system system (1 of 1)
2.5L
2.5L 3.7L
3.7L
A/C RELAY
A/T MAIN RELAY
ABS MOTOR FUSE
ANTI-LOCK BRAKES SYSTEM
AUDIO FUSE (W/ BOSE) TAIL FUSE
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLOWER 2 FUSE
BLOWER FUSE A/C FUSE
BLOWER RELAY
BLU RED/ WIRE
BTN FUSE
C-05
C-07
C-23
COOLING FANS SYSTEM
DEFOG FUSE
DRL FUSE (W/ DRL)
ENGINE 2 FUSE IG FUSE
ENGINE CONTROLS SYSTEM
ENGINE FUSE
EXTERIOR HEADLIGHTS LIGHTS SYSTEM SYSTEM
EXTERIOR LIGHTS, BODY COMPUTER SYSTEMS TO RELAY BLOCK (DIAGRAM 2 OF 2)
FAN FUSE
FOG FUSE SUNROOF FUSE FUSE
FROM
FROM ABS MOTOR FUSE (DIAGRAM 1 OF 2)
FROM MAIN RELAY (DIAGRAM ENG +B FUSE ESCL FUSE 1 OF 2)
FRONT FOG LIGHT RELAY
FUEL PUMP RELAY
FUSE (DIAGRAM 1 OF 2)
GRN/BLU WIRE
GRN/RED WIRE
GRN/YEL WIRE
HAZARD FUSE FUSE
HEADLIGHT RELAY
HORN FUSE
HORN RELAY
MAIN FUSE
MAIN RELAY
P OUTLET (R) FUSE
P SEAT (P) P SEAT (D) FUSE FUSE
P WIND (D) FUSE
P WIND (P) FUSE
PCM FUSE ENGINE FUSE
POWER TOPS SYSTEM
POWER WINDOWS SYSTEM
REAR ACCESSORY
REAR BLOWER RELAY
REAR WINDOW DEFROSTER RELAY
RED WIRE
RED/ BLU WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/ORG WIRE
SEAT HEAT FUSE
SEATS, SEATS SYSTEM MEMORY SYSTEMS
SOCKET
SOUND BODY SYSTEMS COMPUTER, INTERIOR LIGHTS, EXTERIOR LIGHTS SYSTEMS
STARTER RELAY
STARTING/ CHARGING SYSTEM
STOP FUSE
TCM FUSE
TO BLOWER FUSE (DIAGRAM 1 OF 2)
TO ENG +B FUSE (DIAGRAM 1 OF 2)
TO P OUTLET (R) FUSE (DIAGRAM 1 OF 2)
TO RELAY BLOCK (DIAGRAM 2 OF 2)
TO ROOM FUSE (DIAGRAM 2 OF 2)
TRANSMISSIONS SYSTEM
Go to component -> Power distribution circuit, with advanced keyless entry & start system (1 of 2) -> EXTERIOR HEADLIGHTS LIGHTS SYSTEM SYSTEM
