Mazda 6 GH facelift (2009-2013) push button start system w/ advanced keyless entry, push button start system Wiring diagram
This page shows the only wiring diagram for the component.push button start system w/ advanced keyless entry, push button start system, which is found in the car Mazda 6 GH facelift (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram push button start system w/ advanced keyless entry, push button start system (1 of 1)
2.5L
3.7L
A/T
A/T M/T
AUTO DIMMING MIRROR (IN REAR VIEW MIRROR)
BACKUP LIGHT RELAY (3.7L)
BACKUP LIGHT SWITCH (ON TRANSAXLE
BCM (BEHIND LEFT KICK PANEL)
BLK WIRE
BLK/GRN WIRE
BLU WIRE
C-02
C-02 AA
C-21
C-35
C-62
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZARD FUSE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BLOCK (UNDER LEFT SIDE OF DASH)
HOT IN ON OR START
LEFT BACKUP LIGHT RIGHT BACKUP LIGHT
M/T
MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
METER IG FUSE
NCA WIRE
ORG/ WIRE
ORG/BLU WIRE
PUSH BUTTON START SYSTEM W/ ADVANCED KEYLESS ENTRY, PUSH BUTTON START SYSTEM
RED WIRE
RED/GRN WIRE
RELAY ENERGIZED
ROOM FUSE
TCM (REAR OF ENGINE)
TRANSAXLE RANGE SWITCH (2.5L) (LEFT SIDE OF TRANSAXLE)
W/ REAR MOUNT CAMERA
WHT WIRE
YEL WIRE
Go to component -> Backup lamps circuit -> PUSH BUTTON START SYSTEM W/ ADVANCED KEYLESS ENTRY, PUSH BUTTON START SYSTEM
