Mazda 6 GH facelift (2009-2013) meter ig fuse sas fuse Wiring diagram

0810-04 0810-14 0810-15 0810-24 BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE C-08 C-09 C-13 C-24 C-25 C-29 C-30 C-55 CLOCK SPRING (IN STEERING COLUMN) COMPUTER DATA LINES SYSTEM DRIVER SIDE AIR BAG MODULE 1 (IN STEERING WHEEL) DRIVER SIDE AIR BAG MODULE 2 (IN STEERING WHEEL) DRIVER SIDE BUCKLE SWITCH (IN DRIVER'S SEAT BELT BUCKLE ASSEMBLY) DRIVER SIDE PRESSURE FUSE BLOCK (UNDER LEFT SIDE OF DASH) GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/ORG WIRE HOT W/ IG 1 RELAY ENERGIZED HOT IN RUN OR START INFLATOR METER IG FUSE SAS FUSE NCA WIRE ORG/ WIRE PASSENGER SIDE AIR BAG MODULE 1 PASSENGER SIDE AIR BAG MODULE 2 PASSENGER SIDE PRESSURE POWER DISTRIBUTION SYSTEM RED WIRE SAS CONTROL MODULE (UNDER FRONT OF CENTER CONSOLE) SENSOR (IF EQUIPPED) SHORT BAR WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/GRN WIRE
